BARKSDALE

‹

Barksdale B1T-M32SS Housed Bourdon Tube Pressure Switch, M32 Range, 316SS, NEMA 4 New Original 1-year Warranty

›

‹

  • Barksdale B1T-M32SS Housed Bourdon Tube Pressure Switch, M32 Range, 316SS, NEMA 4 New Original 1-year Warranty
  • Barksdale B1T-M32SS Housed Bourdon Tube Pressure Switch, M32 Range, 316SS, NEMA 4 New Original 1-year Warranty

›

Barksdale B1T-M32SS Housed Bourdon Tube Pressure Switch, M32 Range, 316SS, NEMA 4 New Original 1-year Warranty
Barksdale B1T-M32SS single-setpoint Bourdon tube switch, M32 medium pressure, 316SS wetted parts, NEMA 4, for industrial hydraulic and process control.
Contact Us
Specifications
  • Model: B1T-M32SS
  • Series: B1T Housed Bourdon Tube
  • Pressure Range: M32 (Medium Pressure, 0–3200 psi / 0–220 bar)
  • Wetted Parts: 316 Stainless Steel
  • Contact: SPDT Snap-Action
  • Electrical Rating: 10A @ 125/250VAC; 3A @ 480VAC
  • Enclosure: NEMA 4 (Anodized Aluminum)
  • Pressure Connection: 1/4” FNPT Stainless Steel
  • Accuracy: ±1% FS
  • Temp Range: -20°C ~ +80°C
